R580II Waterproof And Dustproof Direct Thermal Printer High-speed 250mm/s Easy Operation

Availability:
Quantity:

The SNBC BTP-R580II thermal receipt printer is ideal for harsh hospitality, QSR and retail environments. The front paper exit allows installation in tight spaces and use as a low-cost kiosk printer.

• Energy Star Certifed – Superior Efficiency Reduces Energy Costs and Reduces Carbon Footprint
• Print Speed Up to 230mm per Second
• Built-In Power Supply
• Gray Scale and Two Color Print Capable
• Dual Interface Standard – USB Interface is on the Main Board
• Serial, Parallel, USB, Ethernet and Wireless WiFi Interface Options
• Stores and Prints Logo Images
• Contains Everything Necessary in the Carton– Including Communication Cables


Max Print Speed - Mono:230mm per Second
Max Print Speed - Gray Scale:150mm per Second
Max Print Speed - Two-Color:120mm per Second
Printing Method:Direct Thermal
Resolution:203 DPI x 203 DPI

Characters Per Line - Font A:
                                         Font B:

42 (80mm) / 37 (58mm)
56 (80mm) / 49 (58mm)
Characters Size - Font A:
                                 Font B:
12 x 24
9 x 17
Paper Roll Type - Width:
Maximum Diameter:
Paper Thickness:
54.5mm ~ 82.5mm
100mm
0.06mm ~ 0.145mm
Auto Paper Cutting Method:Auto-Cutter with Selectable Full or Partial Cut
Reliability - MTBF:
                    MCBF:
     Printhead Life:
            Cutter Life:
360,000 Hours
70,000,000 Lines
Single Color >_ 150 KM / Two Color >_ 75 KM
2,000,000 Cuts
Character Set - Alphanumeric:
International:
Graphic:
95
13
128 x 56 Page
Bar Code - 1D:
                   2D:
UPC-A / UPC-E / EAN8 / EAN13 / Code39 / Code93 / CODE128 / CODABAR / ITF
PDF417 / QR Code / MaxiCode
Interpreter:ESC/POS
Interface:USB+Serial / USB+Parallel / USB+Ethernet / USB+Wireless WiFi / USB Only
Drivers -                               32 bit:
                                32 and 64 bit:
                                             Other:
        Software Development Kit:
POSReady 2009 / 2000 Server / 2000 Prof. / XP Home
Win 8 / Win 7 / Server 2008 / Server 2003 / XP Prof. / Vista

Linux / OPOS / MAC Support / BYJavaPOS Windows / BYJavaPOS Linux
iOS / Android
Drawer Port:Up to 2 Drawers (+24VDC) / Drawer Compulsion
Data Buffer - Rec. Buffer RAM:
RAM Bitmap:
Flash Bitmap:
64KB
128KB
512KB
Power Supply:AC 100 ~ 240 V, 50/60 Hz
Current/Power Usage:2.3A / 60W
Operating Temperature:40° ~ 114°F (5° ~ 45°C)
Operating Humidity:20% ~ 90% RH (Non-Condensing)
Dimensions6-1/8"W x 6-5/16"H x 8-1/16"D
Shipping Weight:7 lbs. (Each Unit)
Safety and EMI:FCC / RoHS


123456
