C61 Industrial Grade Intelligent Handheld Terminal with Keyboard 27/37/47 Optional

C61 is a high-performance industrial grade intelligent handheld terminal with a keyboard launched by Shenzhen Chengcheng. It is developed based on Android 9/11 and uses a Qualcomm eight core processor. It supports optional 27 key/37 key/47 key keyboards, comes with a standard 6700 mAh detachable battery and supports fast charging. It can also be equipped with a controller and a 5200 mAh controller battery, and can be paired with a variety of accessories for powerful configuration.
At the same time, it supports the selection of high-performance barcode scanning, ultra-high frequency reading and writing, NFC and other rich functions. The data collection function is powerful, and combined with a dual frequency WIFI antenna specially optimized for indoor scenes, it can be perfectly applied to various industries such as logistics, warehousing and inventory, production and manufacturing, retail management, asset management, etc., making complex data collection work easy from now on.

Availability:

Quantity:



Inquiry Now Add to Basket

Model:
C61

Product Description

C61 data collector with physical keyboard
system function		communication
operating system	Android 9/11	camera	Rear lens: 13 million pixels with auto focus and LED flash
CPU	Android 9：Qualcomm Snapdragon™ 450 8 core, 1.8 GHz Android 11：Qualcomm Snapdragon™ 662 8 core, 2.0GHz	Expand memory	MicroSD (TF up to 128GB)
Memory	3GB+32GB / 4GB+64GB / 6GB+128GB	GNSS	Integrated GPS, Beidou, GLONASS and Galileo, supports AGPS, built-in antenna
		wireless network	IEEE 802.11a/b/g/n/ac, 2.4GHz and 5GHz Support 802.11d/e/h/i/j/k/r/v, fast roaming Wireless network security management mechanism WFA, WPA and WPA2 Support VoWiFi and hotspot sharing
Language	Multi language support	USB	USB 2.0 (type-C) supports USB OTG
Barcode Scanning		BT	Android 9：BT 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR Android 11：BT 5.1
1D Barcode	UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS...	Other sensors	Accelerometer sensor, electronic compass, light sensor, Gyroscope
2D Barcode	PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX)	WWAN	2G: 850/900/1800/1900MHz 3G: CDMA EVDO: BC0 WCDMA：850/900/1900/2100MHz TD-SCDMA：A/F（B34/B39） 4G: B1/B3/ B5/B7/B8/B20/B38/B39/B40/B41
Specification		Scanning Model
Battery	6700mAh detachable battery, and the optional handle has a 5200mAh detachable battery. It supports QC3.0 fast charging and RTC, and has a built-in 100mAh backup battery.	Scanner	Zebra：SE4710/SE4750SR/SE4750MR/SE4750DP/ SE4850；Honeywell：N6603
Keys	Main keyboard (optional): 27 keys/37 keys/47 keys; Side buttons: 2 scan keys+2 volume keys+1 custom key	RFID（optional）	support 920-925 MHz / 902-928 MHz / 865-868 MHz based on EPC C1 GEN2 / ISO18000-6C
IP level	IP65 IEC sealing standard	Size	202mm x 72.5mm x 32mm
Weight	Host with battery: 370g (including SE4710) /404g (including SE4850)/ 738g (SE4850, UHF, including handle battery)	Operating temperature	-20°C to 50°C
